TPA1654 Description
4.5 V to 36 V Low Supply Current: 0.9 mA per channel Low Offset Voltage: ±1 mV Maximum at 25°C Low Input Bias Current:.
TPA1654 Key Features
- Supply Voltage: 4.5 V to 36 V
- Low Supply Current: 0.9 mA per channel
- Low Offset Voltage: ±1 mV Maximum at 25°C
- Low Input Bias Current: ±30 nA at 25°C
- No ESD Diode to Positive Power Supply
- Gain Bandwidth: 5 MHz
- Slew Rate: 3.5 V/μs
- Low Noise: 62 nV/√Hz at 1 kHz
- Excellent THD + N: 0.001%
