Features Applications - Qualified for Automotive Applications - AEC-Q100 Grade 1, TA: - 40°C to +125°C - Junction Temperature, TJ: - 40°C to +150°C - Input Voltage: 3 V to 42 V - Output Voltage: - Fixed 5 V and 3.3 V - ±2% Output Accuracy Over Line Regulation, Load Regulation, and Operating Temperature Range - Low Current Consumption: - 400-n A Shutdown Current - 3-μA Typical Quiescent Current - 300-m A Maximum Output Current - Low Dropout Voltage: 720 m V Maximum at 200 m A Load Current - Integrated Power-Good Indicator - Adjustable Power-Good Delay Time - Open-Drain Output - Stable with 1-μF to 200-μF Output Capacitor with ESR Range from 0.001 Ω to 10 Ω - Integrated Protection: - Over-Current Protection - Over-Temperature Protection - Package Option: - EMSOP8 - Automotive Clusters and Infotainment - Automotive Headlights and Interior Lighting - Automotive Domain Control - Automotive BCM and Door Handler Description The TPL8034Q series supports operating with 3 V to 42 V (45-V maximum transient voltage). Operating with as low as 3 V allows the TPL8034Q to work well during cold-crank and start-stop conditions. The TPL8034Q products are 3-μA ultra-low quiescent low dropout voltage linear regulators with 300-m A maximum output current capability. The TPL8034Q series integrates an open-drain output power good indicator. The power-good delay time is adjusted with an external capacitor. With the above features , the TPL8034Q products are the optimal solutions for powering the MCU, CAN/LIN transceivers in the always-on applications, and the batteryconnected applications in the automotive systems. The TPL8034Q series provides fixed 5-V and 3.3-V output voltage options. What's more, the TPL8034Q supports a wide range of output capacitors from 1 μF to 200 μF with an ESR range from 0.001 Ω to 10 Ω. The TPL8034Q series integrates over-current protection and over-temperature protection. The TPL8034Q series operates in the ambient temperature range...
