TPM27517 - Single-Channel 5-A High-Speed Low-Side Gate Driver

General Description

The TPM27517 is a single-channel low-side gatedriver for MOSFET, IGBT and GaN power switches.

High sourcing and sinking current capability of 5-A allows improving switching efficiencies by minimizing slew time and switching loss.

5 V input

Key Features

  • Industry-Standard Pin-Out.
  • 4.5-V to 23-V Single-Supply Range.
  • Single Channel 5-A Peak Source and Sink-Drive Current.
  • TTL and CMOS Compatible Threshold.
  • Outputs Held Low During VDD-UVLO or Input Floating.
  • Low Propagation Delay (13-ns Typical).
  • Fast Rise and Fall Times (7-ns and 6-ns Typical).
  • ESD Protection Exceeds JESD 22.
  • 6-kV HBM, 1.5-kV CDM.
  • Available in SOT23-5 Package.

📥 Download Datasheet

Datasheet Details

Part number TPM27517
Manufacturer 3PEAK
File Size 592.52 KB
Description Single-Channel 5-A High-Speed Low-Side Gate Driver
Datasheet download datasheet TPM27517 Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
TPM20PB3D6 20V Dual P-Channel Enhancement Mode MOSFET TECH PUBLIC
TPM215HW01-HGEL03 TFT LCD Top Victory Electronics
TPM2323-30 MICROWAVE POWER GaAs FET Toshiba Semiconductor
TPM2626-14 MICROWAVE SEMICONDUCTOR Toshiba Semiconductor
TPM2626-30 MICROWAVE POWER GAAS FET Toshiba Semiconductor

Other Datasheets by 3PEAK

Part Number Description
TPM27523 Dual 5-A Low-side Gate Driver
TPM27524 Dual 5-A Low-side Gate Driver
TPM27524Q Automotive Dual 5-A High-Speed Low-Side Gate Driver
TPM27525 Dual 5-A Low-side Gate Driver
TPM27526 Dual 5-A Low-side Gate Driver

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
TPM27517 Single-Channel 5-A High-Speed Low-Side Gate Driver Features  Industry-Standard Pin-Out  4.5-V to 23-V Single-Supply Range  Single Channel 5-A Peak Source and Sink-Drive Current  TTL and CMOS Compatible Threshold  Outputs Held Low During VDD-UVLO or Input Floating  Low Propagation Delay (13-ns Typical)  Fast Rise and Fall Times (7-ns and 6-ns Typical)  ESD Protection Exceeds JESD 22 − 6-kV HBM, 1.5-kV CDM  Available in SOT23-5 Package Applications  Switched-Mode Power Supplies  DC-DC Converters  Motor Control, Solar Inverters, UPS  Gate & IGBT Drive Description The TPM27517 is a single-channel low-side gatedriver for MOSFET, IGBT and GaN power switches.
