ABOV SEMICONDUCTOR MC81F4104

MC81F4104 is a CMOS 8 bit MCU which provides a 4K bytes FLASH-ROM and 192 bytes RAM. It has following major features, 12 bit ADC : It has 7(5) ch A/D Converter which can be used to measure minute electronic voltage and currents. 800 Core use a divided system clock but 810 Core use the system clock directly 1.2 Features ROM(FLASH) : 4K Bytes (Endurance: 100 cycle) SRAM : 192 Bytes Minimum instruction execution time 166n sec at 12MHz (NOP instruction) 12-bit A/D converter : 7 ch General Purpose I/O(GPIO) 10-pin PKG: 8 8-pin...

Part No.	MC81F4104
Datasheet	MC81F4104 Download
Manufacturer	ABOV SEMICONDUCTOR
Description	8-BIT SINGLE-CHIP MICROCONTROLLERS
Buy	Stock & Price

DESCRIPTION

810 Core : Same with ABOV’s 800 Core but twice faster. 800 Core use a divided system clock but 810 Core use the system clock directly 1.2

FEATURES

ROM(FLASH) : 4K Bytes (Endurance: 100 cycle) SRAM : 192 Bytes Minimum instruction execution time 166n sec at 12MHz (NOP instruction) 12-bit A/D converter : 7 ch General Purpose I/O(GPIO) 10-pin PKG: 8 8-pin PKG: 6 Timer/Counter 8Bit x 2ch PWM 10 bit High Speed PWM * 1ch Watchdog timer(WDT) : 8Bit x 1 ch Basic Interval Timer(BIT) : 8Bit x 1ch Interrupt Source : 9 ch External Interrupts : 3 ch Timer 2/3 Match/Overflow WDT, BIT Power On Reset (POR) Low Voltage Reset (LVR) 8 4 level detector (2.4/2.7/3.0/4.0V) Power Down Mode Stop mode Sleep mode Operating Voltage & Frequency 4.0V – 5.5V (at 1.0 – 12.0MHz) 2.7V – 5.5V (at 1.0 – 8.0MHz) 2.2V – 5.5V (at 1.0 – 4.2MHz) Operating Temperature - 40°C ~ 85°C Oscillator Type Crystal, Ceramic, RC for main clock Internal Oscillator (8MHz/4MHz/2MHz/1MHz) Package 10 SSOP, 8 PDIP/SOP Available Pb...
