ABOV MC95FG308
The MC95FG308 is an advanced CMOS 8-bit microcontroller with 8Kbytes of FLASH. This is powerful microcontroller which provides a highly flexible and cost effective solution to many embedded control applications. This provides the following features: 8Kbytes of FLASH, 256bytes of internal SRAM, 256bytes of external SRAM, 512bytes of Data EEPROM, general purpose I/O, 8/16-bit timer/counter, watchdog timer, watch timer, SPI, USART, I2C, on-chip POR, BOD, 12-bit A/D converter, analog comparator, buzzer driving port, 10-bit high speed PWM output, on-chip oscillator and clock circuitry.| Part No. | MC95FG308 |
|---|---|
| Datasheet | MC95FG308 Download |
| Manufacturer |  ABOV |
| Description | 8-BIT MICROCONTROLLERS |
| Buy | Stock & Price |
DESCRIPTION
The MC95FG308 also supports power saving modes to reduce power consumption. Device Name MC95FG308D MC95FG308U MC95FG308L MC95FG308M MC95FG308H MC95FG208D MC95FG208R MC95FG208M MC95FG208H FLASH 8Kbytes IRAM 256bytes XRAM 256bytes Table 1.1 Ordering Information of MC95FG308 EEPROM 512bytes ADC 15inputs 12inputs 10inputs 8inputs I/O PORT 30 26 18 14 Package 32SOP 32QFN 32LQFP 28SOP 28TSSOP 20SOP 20TSSOP 16SOP 16TSSOP 3 ABOV Semiconductor Co., Ltd. 1.2FEATURES
MC95FG308 / MC95FG208● CPU – 8-bit CISC core (8051 Compatible, 2 clock per cycle)
● 8Kbytes On-Chip FLASH – Optional boot code section with protection – Endurance : 10,000 times at room temperature – Retention : 10 years
● 256bytes SRAM
● 256bytes XRAM
● 512bytes Data EEPROM – Endurance : 300,000 times at room temperature – Retention : 10 years
● General Purpose I/O (GPIO) – 30Ports (P0[7:0], P1[6:0], P2[6:0], P3[7:0]): 32-Pin – 26Ports (P0[7:0], P1[6:0], P2[2:0], P3[7:0]): 28-Pin – 18Ports (P0[7:0], P1[6:0], P2[2:0]):...
