Datasheet Details
| Part number | ACM3128A |
|---|---|
| Manufacturer | ACME |
| File Size | 2.02 MB |
| Description | Analog Input Class-D Audio Amplifier |
| Datasheet | ACM3128A-ACME.pdf |
|
|
| Part number | ACM3128A |
|---|---|
| Manufacturer | ACME |
| File Size | 2.02 MB |
| Description | Analog Input Class-D Audio Amplifier |
| Datasheet | ACM3128A-ACME.pdf |
|
|
|
- 2×42W, 1% THD+N, 24V, 6Ω, BTL The ACM3128A is a stereo/mono, Class D audio amplifier - 1×84W, 1% THD+N, 24V, 3Ω, PBTL delivers up to 2×42W into 6Ω stereo mode and 1×84W into Zhisheng Confidential ï‚Ÿ ExcellentAudioPerformance - THD+N ≤ 0.02% at 1W, 1kHz, 4Ω, PVDD = 24V - Higher Order Modulator Enable Better THD+N for full audio band - Idle switching A-weighted noise ≤ 63 í µí±¢í µí±¢í µí±¢í µí±¢í µí±…í µí±…í µí±…í µí±…í µí±…í µí±… ï‚Ÿ Efficient Class-D Operation - >90% efficient Class-D operation eliminates need for heat sink - Low Idle Current: <24mA, PVDD=12V, LC Filter=10uH+0.68uF - Patented Modulation Schemes to Minimize inductor ripple Current for all output power level - Class-H Control improves efficiency for full output power range ï‚Ÿ Low EMI Technology - Spread Spectrum Option - 180Ëš PWM Phase Shift ï‚Ÿ Gain Management - 20dB, 26dB, 30dB, 34dB fixed gain setting - Mute Operation to stop PWM switching - Programmable Power Limit ï‚Ÿ Analog Protections a 3Ω load in mono mode while offering up to 92% efficiency.
In order to minimize power dissipation, a new patented modulation scheme - Dynamic PWM been used to minimize inductor loss for full output power range.
The ACM3128A operates from a single +4.5V to +26.4V supply, driving the load in BTL or PBTL configuration.
