Datasheet Summary
DIN Rail
AC-DC Converter
Click to
ORDER samples
The AMED100S-GY is slim DIN-rail mounting AC/DC converter that Features a cost-effective and energy efficient design. It accepts an input voltage range of 90-264VAC and an output voltage range from 12-48V. Measuring 55.00 x 100.00 x 92.00mm, the converter is easy to install and remove for maintenance, while efficiently organizing all your electrical cables.
This new series offers great operating temperatures, from -10°C to 60°C and Features an isolation of 3000VAC for improved reliability and system safety. Furthermore, a high MTBF of 1,885,100h, output over-load protection, output short circuit protection, and output...
