AiT Semiconductor AD-IB0512LS-1WR3
The AD-IBxxxxLS-1WR3 series is designed for High efficiency up to 74% applications in distributed power systems that I/O Isolation test voltage 1500VDC require the generation of a power supply isolated -40°C to +85°C Working Temperature Range from the input power. They are suitable for: pure MTBF ≥3500KHrs digital circuits, general low frequency analog Output short-circuit, over-current protection circuits, relay drive circuits, data exchange circuits, Industry standard pin-out, Small SIP package, etc.| Part No. | AD-IB0512LS-1WR3 |
|---|---|
| Datasheet | AD-IB0512LS-1WR3 Download |
| Manufacturer |  AiT Semiconductor |
| Description | DCDC CONVERTER |
| Buy | Stock & Price |
DESCRIPTION
FEATURES
The AD-IBxxxxLS-1WR3 series is designed for● High efficiency up to 74% applications in distributed power systems that
● I/O Isolation test voltage 1500VDC require the generation of a power supply isolated
● -40°C to +85°C Working Temperature Range from the input power. They are suitable for: pure
● MTBF ≥3500KHrs digital circuits, general low frequency analog
● Output short-circuit, over-current protection circuits, relay drive circuits, data exchange circuits,
● Industry standard pin-out, Small SIP package, etc. plastic house. ORDERING INFORMATION Part Number AD-IB0505LS-1WR3 AD-IB0509LS-1WR3 AD-IB0512LS-1WR3 AD-IB0515LS-1WR3 AD-IB1205LS-1WR3 AD-IB1209LS-1WR3 AD-IB1212LS-1WR3 AD-IB1215LS-1WR3 AD-IB2405LS-1WR3 AD-IB2409LS-1WR3 AD-IB2412LS-1WR3 AD-IB2415LS-1WR3 Input Voltage (VDC) Nominal (Range) 5V (4.75~5.25) 12V (11.4~12.6) 24V (22.8~25.2) Output Voltage Current (mA) (VDC) Max/Min 5 200/20 9 112/11.2 12 84/8.4 15 67/6.7 5 200/20 9 112/11.2 12 84/8.4 15 67/6.7 5...
