APX632 - High Sensitivity Hall-Effect Sensor

ANPEC

General Description

The APX632 is an integrated Hall-Effect sensor latch IC designed for electric commutation of three-phase Brushless DC motor applications.

The APX632 is available in a low cost SOT-23-3 package.

Key Features

On-Chip Hall Sensor.
Wide Operating Voltage Range: 2.2V to 24V.
Low Operating Supply Current.
Built-in Pull-up Resistor.
High Sensitivity Hall Effect Sensor IC: ±60G.
3 Pin SOT-23 Package.
Lead Free and Green Devices Available (RoHS Compliant).

📥 Download Datasheet

APX632 high sensitivity hall-effect sensor by ANPEC - Datasheet Preview

Datasheet Details

Part number	APX632
Manufacturer	ANPEC
File Size	155.08 KB
Description	High Sensitivity Hall-Effect Sensor
Datasheet	APX632 Datasheet

📁 Similar Datasheet

Part Number	Description	Manufacturer
APX6219	PWM Stepper Motor Driver	Anpec Electronics
APX6223	DSC Motors Driver	Anpec Electronics
APX1117	1A LOW DROPOUT POSITIVE ADJUSTABLE	Diodes Incorporated
APX1690	9-Set Over Voltage Protector	Anpec Electronics
APX321	SINGLE/DUAL/QUAD OPERATIONAL AMPLIFIER	Diodes

Other Datasheets by ANPEC

Part Number	Description
APX6861	Direct PWM Variable Speed Fan Motor Driver
APX6980	Single-Phase Full-Wave Motor Driver
APX284	High Sensitivity Hall-Effect Sensor
APX284A	High Sensitivity Hall-Effect Sensor
APX285	High Sensitivity Hall-Effect Sensor

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text

APX632 High Sensitivity Hall Effect Sensor Latch IC Features • On-Chip Hall Sensor • Wide Operating Voltage Range: 2.2V to 24V • Low Operating Supply Current • Built-in Pull-up Resistor • High Sensitivity Hall Effect Sensor IC: ±60G • 3 Pin SOT-23 Package • Lead Free and Green Devices Available (RoHS Compliant) Applications • Brushless DC Motor • Brushless DC Fan • Revolution Counting • Speed Measurement General Description The APX632 is an integrated Hall-Effect sensor latch IC designed for electric commutation of three-phase Brushless DC motor applications. The APX632 is available in a low cost SOT-23-3 package.
