APT30D100BCT - ULTRAFAST SOFT RECOVERY RECTIFIER DIODES

Key Features

  • Ultrafast Recovery Times.
  • Soft Recovery Characteristics.
  • Popular TO-247 Package.
  • Low Forward Voltage.
  • High Blocking Voltage.
  • Low Leakage Current.

📥 Download Datasheet

Datasheet Details

Part number APT30D100BCT
Manufacturer Advanced Power Technology
File Size 59.32 KB
Description ULTRAFAST SOFT RECOVERY RECTIFIER DIODES
Datasheet download datasheet APT30D100BCT Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
APT30D120B Ultrafast Rectifier INCHANGE
APT30DC60HJ SiC Diode Full Bridge Power Module Microsemi
APT30DF100HJ Fast Diode Full Bridge Power Module Microsemi
APT30DF120HJ Fast Diode Full Bridge Power Module Microsemi
APT30DF20HJ Fast Diode Full Bridge Power Module Microsemi

Other Datasheets by Advanced Power Technology

Part Number Description
APT30D100BCTG ULTRAFAST SOFT RECOVERY RECTIFIER DIODE
APT30D100BCA ULTRAFAST SOFT RECOVERY RECTIFIER DIODES
APT30D100BCAG ULTRAFAST SOFT RECOVERY RECTIFIER DIODE
APT30D100B ULTRAFAST SOFT RECOVERY RECTIFIER DIODE
APT30D100BG ULTRAFAST SOFT RECOVERY RECTIFIER DIODE

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
1 3 TO -24 2 1 - Anode 1 2 - Common Cathode Back of Case - Cathode 3 - Anode 2 1 2 3 7 APT30D100BCT 1000V 2x30A ULTRAFAST SOFT RECOVERY RECTIFIER DIODES PRODUCT APPLICATIONS • Parallel Diode • • • • • -Switchmode Power Supply -Inverters Free Wheeling Diode -Motor Controllers -Converters Snubber Diode Uninterruptible Power Supply (UPS) Induction Heating High Speed Rectifiers PRODUCT FEATURES • Ultrafast Recovery Times • Soft Recovery Characteristics • Popular TO-247 Package • Low Forward Voltage • High Blocking Voltage • Low Leakage Current PRODUCT BENEFITS • Low Losses • Low Noise Switching • Cooler Operation • Higher Reliability Systems • Increased System Power Density MAXIMUM RATINGS Symbol VR VRRM VRWM IF(AV) IF(RMS) IFSM TJ,TSTG TL Characteristic / Test Conditions Maximum D.
