AZ1023-04F
Features
ESD Protect for 4 high-speed I/O channels Provide ESD protection for each line to
IEC 61000-4-2 (ESD) ±15k V (air), ±8k V (contact) IEC 61000-4-4 (EFT) 20A (5/50ns) IEC 61000-4-5 (Lightning) 3A (8/20µs)
For low operating voltage of 3.3V and below Ultra low capacitance: 0.18p F typical Fast turn-on and ultra-low clamping voltage Array of ESD rated diodes with internal equivalent TVS (Transient Voltage Suppression) diode Solid-state silicon-avalanche and active circuit triggering technology Green part
Applications
HDMI 1.3 & 1.4, and 2.0 version Display Port 1.1 & 1.2 and 1.3 version USB3.0 & 3.1 interfaces USB Type-C interface SATA and e SATA interfaces Hand Held Portable Applications
Description
AZ1023-04F is a design which includes ESD rated diode arrays to protect high speed data interfaces. The AZ1023-04F has been specifically designed to protect sensitive ponents which are connected to data and transmission lines from over-voltage damage caused by Electrostatic Discharging...
