| Part number | AZ2025-01H |
|---|---|
| Datasheet | AZ2025-01H-AmazingMicroelectronic.pdf |
| File Size | 193.51 KB |
| Manufacturer | Amazing Microelectronic |
| Description | Transient Voltage Suppressing Device |
|
|
AZ2025-01H is a design which includes a bi-directional surge rated clamping cell to protect one power line, or one control line, or one low speed data line in an electronic systems. The AZ2025-01H has been specifically designed to protect sensitive ponents which are connected to power and control lines from over-voltage damage and latch-up caused by Electrostatic Discharging (ESD), Electrical Fast Transients (EFT),...
