AZ4020-01F
Features
ESD Protect for 1 Line with Unidirectional. Provide ESD protection for a line to IEC 61000-4-2 (ESD) ±30k V (air/contact), IEC 61000-4-5 (Lightning) 58A (8/20µs) Suitable for, 20V and below, operating voltage applications Ultra Small package saves board space Protect one I/O line or one power line Fast turn-on and Low clamping voltage Solid-state silicon-avalanche and active circuit triggering technology Green part
Applications
AZ4020-01F is a unique design which includes proprietary clamping cell in a single package. During transient conditions, the proprietary clamping cell prevents over-voltage on the power line or control/data lines, protecting any downstream ponents. AZ4020-01F may be used to meet the ESD immunity requirements of IEC 61000-4-2, Level 4 (±15k V air, ±8k V contact discharge).
Circuit Diagram / Pin Configuration
Power Supply Protection
USB Power Delivery
Cellular Handsets and Accessories
Small Panel Modules
PDA’s
Portable Devices
Digital...
