AZM-SIM02-03F
Features
- Monolithic 3-line EMI symmetrical I/O low-pass filter with 1-channel TVS protector
- ESD Protect for input and output of each line
- 0.4mm pin pitch
- Provide ESD protection for each I/O to
IEC 61000-4-2 (ESD) ±8k V (contact) IEC 61000-4-2 (ESD) ±15k V (air)
- For low operating voltage applications: 5V and below.
- Fast turn-on and Low clamping voltage
- Solid-state silicon-avalanche and active circuit triggering technology
- MLPD (Micro Leadframe Package Dual) packaging and small PCB space occupying: ≤ 2.6 mm2
- High reliability provided by monolithic integration
- Lead free package
- Green Part
Applications
- SIM card data lines of mobile phones
- Hand Held Portable Applications: EMI filtering and ESD protection for I/O ports and keypads
Description the device from destruction or interference when subjected to ESD stress up to IEC 61000-4-2, Level 4 (±8k V contact, ±15k V air discharge).
Circuit Diagram
The Circuit for One Line
Pin Configuration (Bottom Side)
VE I1 I2...
