AZRS485E
Features
- Integrated Transient Voltage Suppressor (TVS) in the Transceiver IC
- TVS Protection for Bus Terminals : ±15 k V IEC 61000-4-2, Contact Discharge ±18 k V IEC 61000-4-2, Air-Gap Discharge ±15 k V EIA/JEDEC Human Body Model
- HBM ±8k V ESD Protection for all pins
- MM ±800V ESD Protection for all pins
- Latchup immunity up to ±400m A for all pins.
- High CDM protection up to ±1k V for all pins.
- Meet the Requirements of the EIA/TIA-485
Standards with 5V Power Supply
- True Fail-Safe Receiver While Maintaining
EIA/TIA-485 patibility
- Data Rate up to 10Mbps
Hot-Swap Glitch free Protection on Control Inputs
- High driving ability of VOD2 up to 2.3V
- Up to 256 Transceivers on the Bus
The AZRS485E features a fail-safe receiver, which guarantees the output of the receiver to be logic high when the differential inputs (bus pins, A and B) of the receiver are open, short or idle under abnormal operating conditions. The AZRS485E features a hot-swap glitch-free design which guarantees...
