HCPL-0630 - High Speed TTL Compatible Optocouplers

This page provides the datasheet information for the HCPL-0630, a member of the HCPL-0600 High Speed TTL Compatible Optocouplers family.

Product Overview

Avago

📥 Download Datasheet

Datasheet Details

Part number	HCPL-0630
Manufacturer	Avago
File Size	383.96 KB
Description	High Speed TTL Compatible Optocouplers
Datasheet	HCPL-0630 Datasheet
Additional preview pages of the HCPL-0630 datasheet.

HCPL-0630 Product details

Description

The 6N137, HCPL-26xx/06xx/4661, HCNW137/26x1 are optically coupled gates that combine a GaAsP light emitting diode and an integrated high gain photo detector.

An enable input allows the detector to be strobed.

The output of the detector IC is an open collector Schottkyclamped transistor.

Features

15 kV/µs minimum Common Mode Rejection (CMR) at VCM = 1 kV for HCNW2611, HCPL-2611, HCPL-4661, HCPL-0611, HCPL-0661.
High speed: 10 MBd typical.
LSTTL/TTL compatible.
Low input current capability: 5 mA.
Guaranteed AC and DC performance over temper ature: -40 °C to +85 °C.
Available in 8-Pin DIP, SOIC-8, widebody packages.
Strobable output (single channel products only).
Safety approval UL recognized - 3750 Vrms fo.
