HCPL-316J - 2.5 Amp Gate Drive Optocoupler

Product Overview

Avago

Datasheet Details

Part number	HCPL-316J
Manufacturer	Avago
File Size	387.82 KB
Description	2.5 Amp Gate Drive Optocoupler
Datasheet	HCPL-316J Datasheet
Additional preview pages of the HCPL-316J datasheet.

Product details

Description

Avago’s 2.5 Amp Gate Drive Optocoupler with Integrated Desaturation (VCE) Detection and Fault Status Feedback makes IGBTVCE fault protection compact, affordable, and easy-to-implement while satisfying worldwide safety and regulatory requirements.

Features

2.5 A maximum peak output current.
Drive IGBTs up to IC = 150 A, VCE = 1200 V.
Optically isolated, FAULT status feedback.
SO-16 package.
CMOS/TTL compatible.
500 ns max. switching speeds Features (continued).
“Soft” IGBT turn-off.
Integrated fail-safe IGBT protection.
Desat (VCE) detection .
Under Voltage Lock-Out protection (UVLO) with hysteresis.
User configurable: inverting, noninve.
