ACPL-W61L - Low-Power 10-MBd Digital CMOS Optocouplers

This page provides the datasheet information for the ACPL-W61L, a member of the ACPL-064L Low-Power 10-MBd Digital CMOS Optocouplers family.

Datasheet Summary

Description

The Broadcom® low-power ACPL-x6xL digital optocouplers combine an AlGaAs light emitting diode (LED) and an integrated high gain photodetector.

The optocoupler consumes low power, at maximum 1.3 mA IDD current per channel across temperature.

Features

  • Low IDD current: 1.3 mA/channel maximum.
  • Low input current: 1.6 mA.
  • Built-in slew-rate controlled outputs.
  • 20 kV/µs minimum Common-Mode Rejection (CMR) at VCM = 1000V.
  • High speed: 10 MBd minimum.
  • Guaranteed AC and DC performance over wide temperature:.
  • 40°C to +105°C.
  • Package selection: SO-5, SO-8, stretched SO-6, and stretched SO-8.
  • Safety approval.
  • UL 1577 recognized: 3750 Vrms for 1 minute for ACPL-064L/M61L and 5000 Vrms for 1 minute.

📥 Download Datasheet

Datasheet preview – ACPL-W61L

Datasheet Details

Part number ACPL-W61L
Manufacturer Broadcom
File Size 896.96 KB
Description Low-Power 10-MBd Digital CMOS Optocouplers
Datasheet download datasheet ACPL-W61L Datasheet
Additional preview pages of the ACPL-W61L datasheet.

📁 Similar Datasheet

  • ACPL-W61L - Ultra-Low-Power 10 MBd Digital CMOS Optocouplers (AVAGO)
  • ACPL-W611 - High Speed TTL Optocoupler (Avago)
  • ACPL-W60L - High Speed LVTTL Optocoupler (AVAGO)
  • ACPL-W63L - High Speed LVTTL Optocoupler (AVAGO)
  • ACPL-W302 - 0.4 Amp Output Current IGBT Gate Driver Optocouplers (Avago Technologies)
  • ACPL-W302-000E - 0.4 Amp Output Current IGBT Gate Driver Optocouplers (Avago Technologies)
  • ACPL-W302-060E - 0.4 Amp Output Current IGBT Gate Driver Optocouplers (Avago Technologies)
  • ACPL-W302-500E - 0.4 Amp Output Current IGBT Gate Driver Optocouplers (Avago Technologies)
  • ACPL-W302-560E - 0.4 Amp Output Current IGBT Gate Driver Optocouplers (Avago Technologies)
  • ACPL-W314 - 0.6 Amp Output Current IGBT Gate Driver Optocoupler (Avago Technologies)
Other Datasheets by Broadcom
  • ACPL-W60L - High-Speed LVTTL Optocoupler
  • ACPL-W63L - High-Speed LVTTL Optocoupler
  • ACPL-W346 - GaN and SiC MOSFET Gate Drive Optocoupler
  • ACPL-W349 - 2.5-Amp Output Current SiC/GaN MOSFET and IGBT Gate Drive Optocoupler
  • ACPL-W50L - Digital Optocoupler
  • ACPL-054L - Digital Optocoupler
  • ACPL-064L - Low-Power 10-MBd Digital CMOS Optocouplers
  • ACPL-071L - Single-Channel and Dual-Channel High-Speed 15-MBd CMOS Optocoupler

Full PDF Text Transcription

Click to expand full text
ACPL-064L, ACPL-M61L, ACPL-W61L, ACPL-K64L Low-Power 10-MBd Digital CMOS Optocouplers Data Sheet Description The Broadcom® low-power ACPL-x6xL digital optocouplers combine an AlGaAs light emitting diode (LED) and an integrated high gain photodetector. The optocoupler consumes low power, at maximum 1.3 mA IDD current per channel across temperature. With a forward LED current as low as 1.6 mA, most microprocessors can directly drive the LED. An internal Faraday shield provides a guaranteed commonmode transient immunity specification of 20 kV/µs. Maximum AC and DC circuit isolation is achieved while maintaining TTL/CMOS compatibility. The optocouplers' CMOS outputs are slew-rate controlled and designed to allow the rise and fall time to be controlled over a wide load-capacitance range.
