OPA2344 - OPERATIONAL AMPLIFIER

Download the OPA2344 datasheet PDF. This datasheet also covers the OPA2344_Burr variant, as both devices belong to the same operational amplifier family and are provided as variant models within a single manufacturer datasheet.

General Description

The OPA344 and OPA345 series rail-to-rail CMOS operational amplifiers are designed for precision, lowpower, miniature applications.

The OPA344 is unity gain stable, while the OPA345 is optimized for gains greater than or equal to five, and has a gain-bandwidth product of 3MHz.

Key Features

  • q q q q RAIL-TO-RAIL INPUT RAIL-TO-RAIL OUTPUT (within 1mV) LOW.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (OPA2344_Burr-BrownCorporation.pdf) that lists specifications for multiple related part numbers.

📁 Similar Datasheet

Part Number Description Manufacturer
OPA2344 Operational Amplifier Texas Instruments
OPA2340 Operational Amplifier Texas Instruments
OPA2345 Operational Amplifier Texas Instruments
OPA2348 CMOS Operational Amplifier Texas Instruments
OPA2348-Q1 CMOS Operational Amplifier Texas Instruments

Other Datasheets by Burr-Brown (Texas Instruments)

Part Number Description
OPA234 SINGLE-SUPPLY OPERATIONAL AMPLIFIERS
OPA2340 OPERATIONAL AMPLIFIER
OPA2341 OPERATIONAL AMPLIFIER
OPA2342 OPERATIONAL AMPLIFIER
OPA2343 OPERATIONAL AMPLIFIER

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
® OPA OPA 344 OPA OPA344 434 4 OPA2344 OPA4344 OPA ® 345 342 OPA345 OPA2345 OPA4345 For most current data sheet and other product information, visit www.burr-brown.com LOW POWER, SINGLE-SUPPLY, RAIL-TO-RAIL OPERATIONAL AMPLIFIERS MicroAmplifier ™ Series FEATURES q q q q RAIL-TO-RAIL INPUT RAIL-TO-RAIL OUTPUT (within 1mV) LOW QUIESCENT CURRENT: 150µA typ MicroSIZE PACKAGES SOT23-5 MSOP-8 TSSOP-14 DESCRIPTION The OPA344 and OPA345 series rail-to-rail CMOS operational amplifiers are designed for precision, lowpower, miniature applications. The OPA344 is unity gain stable, while the OPA345 is optimized for gains greater than or equal to five, and has a gain-bandwidth product of 3MHz. The OPA344 and OPA345 are optimized to operate on a single supply from 2.5V and up to 5.
