SS13 Datasheet | Continental Device India

DESCRIPTION SYMBOL SS12 SS13 SS14 SS15 SS16 SS18 SS110 Maximum Peak Repetitive Reverse Voltage Maximum RMS Voltage Maximum DC Blocking Voltage VRRM 20 30 40 50 60 80 100 VRMS 14 21 28 35 42 56 VDC 20 30 40 50 60 80 100 Maximum Average Forward Rectified Current at TL=100o C I(AV) Peak Forward Surge Current 8.3ms single half sine-wave superimposed on rated load IFSM Maximum Voltage at IF=1.0A VF 0.45 0.55 0.6 Maximum DC Reverse Current Tj=25o C at Rated DC Blocking Voltage Tj=100o C 1.0 10 Junction Capacitance - CJ TYP110 Thermal Resistance Junction to Lead Rth (J-L) TYP20 Operating Junction Temperature Range Tj - 55 to +150 Storage Temperature Range Tstg - 55 to +150 - Measured at 1MHz and applied reverse voltage of 4.0 V DC UNIT V V V V m A m A p F ºC/W ºC ºC SS12_SS110Rev_1 280907E Continental Device India Limited Data Sheet Page 1 of...
