CRNT230C65
Features
1.Easy to use, patible with standard gate drivers 2.Excellent QG x RDS(on) figure of merit (FOM) 3.Low QRR, no free-wheeling diode required 4.Low switching loss 5.Ro HS pliant and Halogen-free
Applications
1.High efficiency power supplies 2.Tele and data 3.Automotive 4.Servo motors
3 Lead TO-220
Product summary
VDSS
RDS(ON),typ
230 mΩ
QG,typ
12 n C
QRR,typ
38 n C
Packaging
Part Number
Package
Packaging
3 Lead TO-220
Tube
Maximum ratings, at TC=25 °C, unless otherwise specified
Symbol
Parameter
Continuous drain current @TC=25°C Continuous drain current @TC=100°C
Pulsed drain current @TC=25°C (pulse width: 10us) Pulsed drain current @TC=150°C (pulse width: 10us)
VDSS VTDSS
Drain to source voltage (TJ = -55°C to 150°C) Transient drain to source voltage a
VGSS Gate to source voltage
Maximum power dissipation @TC=25°C
Operating temperature
Case Junction
Storage temperature
TCSOLD Soldering peak...
