CN3903 Datasheet 36v/3.5a 500khz Synchronous Step-down Converter

Manufacturer: Chipnet

Overview: Chipnet CN3903 36V/3.5A500KHzSynchronousStep-DownConverter.

Datasheet Details

Part number CN3903
Manufacturer Chipnet
File Size 516.27 KB
Description 36V/3.5A 500KHz Synchronous Step-Down Converter
Datasheet CN3903-Chipnet.pdf

General Description

The CN3903 is alow EMI signature, asynchronous, step-down, switch-mode converter with internal power MOSFETs.

It offers a very pact solution to provide a 3.5A continuous current over a wide input supply range, with excellent load and line regulation.CN3903 achieves low EMI signature with wellcontrolledswitching edges.Fault condition protection includesprogrammable-output over-voltage protection,Constant on time Mode, and thermalshutdown.

CN3903 requires a minimal number of readilyavailablestandard external ponents.

Key Features

  • Wide 4.5V to 36V Operating Input Range.
  • 3.5A Continuous Output Current.
  • 500KHz Switching Frequency.
  • Short Protection with Hiccup-Mode.
  • Built-in Over Current Limit.
  • Programmable Output Over-Voltage Protection.
  • DCM Mode for High Efficiency in Light Load.
  • Integrated internal Soft-Start.
  • 120/80mΩLowRDS(ON) Internal MOSFETs.
  • Output Adjustable from 0.925V.
  • Low EMI Signature.
  • 100% Duty cycle.
