Clare IAD110P
The IAD110P Multifunction Telecom switch combines a 350V Form A relay and two optocouplers in a single package. The relay uses optically coupled MOSFET technology to provide 1500V of input to output isolation. The efficient MOSFET switch and photovoltaic die uses Clare’s patented OptoMOS architecture.| Part No. | IAD110P |
|---|---|
| Datasheet | IAD110P Download |
| Manufacturer |  Clare |
| Description | Integrated Telecom Circuits |
| Buy | Stock & Price |
FEATURES
● Three Functions in One Package● Small 16 Pin SOIC Package (PCMCIA Compatible)
● Bi-Directional Current Sensing
● Bi-Directional Current Switching
● Replaces up to Three or Four Components
● 3750VRMS Input/Output Isolation
● FCC Compatible
● No EMI/RFI Generation
● Machine Insertable, Wave Solderable
● Tape & Reel Versions Available
APPLICATIONS
● Telecommunications● Telecom Switching
● Tip/Ring Circuits
● Modem Switching (Laptop, Notebook, Pocket Size)
● Hookswitch
● Dial Pulsing
● Ground Start
● Ringer Injection
● Instrumentation
● Multiplexers
● Data Acquisition
● Electronic Switching
● I/O Subsystems
● Meters (Watt-Hour, Water, Gas)
● Medical Equipment-Patient/Equipment Isolation
● Security
● Aerospace
● Industrial Controls
DESCRIPTION
The optically coupled input uses highly efficient GaAIAs infrared LEDs. IAD110P’s allow telecom circuit designers to combine three discrete functions in a single component. The IAD110P’s small package uses less space than traditional discrete component solutions.
