Document 1635-1
Shielded Power Inductors
- XGL6030
Halogen Free
AEC
Q200 +125°C
Typical L vs Frequency
- Industry’slowestDCR&ultralowAClossesoverawidefrequencyrange
- AEC-Q200 qualified
- Superior current handling with soft saturation characteristics
- Wide inductance range from 0.065 to 18 µH
- Designer’s Kit C496 contains 3 of each value
Core material posite Core and winding loss See .coilcraft./coreloss Environmental RoHS pliant, halogen free Terminations RoHS pliant tin-silver (96.5/3.5) over copper. Other terminations available at additional cost. Weight: 0.69
- 0.76 g Operating voltage: 80 V7 Ambient...
