BC807-25 - 45V PNP SMALL SIGNAL TRANSISTOR

Diodes Incorporated

Download the BC807-25 datasheet PDF. This datasheet also covers the BC807-16 variant, as both devices belong to the same 45v pnp small signal transistor family and are provided as variant models within a single manufacturer datasheet.

Key Features

Ideally Suited for Automatic Insertion.
Epitaxial Planar Die Construction.
Complementary NPN Types Available (BC817).
For switching and AF Amplifier.

📥 Download Datasheet

BC807-25 45v pnp small signal transistor by Diodes Incorporated - Datasheet Preview — Note: The manufacturer provides a single datasheet file (BC807-16-DIODES.pdf) that lists specifications for multiple related part numbers.

Datasheet Details

Part number	BC807-25
Manufacturer	Diodes Incorporated
File Size	392.92 KB
Description	45V PNP SMALL SIGNAL TRANSISTOR
Datasheet	BC807-25 Datasheet

📁 Similar Datasheet

Part Number	Description	Manufacturer
BC807-25	EPITAXIAL PLANAR PNP TRANSISTOR	KEC
BC807-25	PNP Transistor	NXP
BC807-25	500mA PNP general-purpose transistors	nexperia
BC807-25	PNP Plastic-Encasulate Transistor	Taiwan Semiconductor
BC807-25	PNP SILICON TRANSISTOR	UTC

Other Datasheets by Diodes Incorporated

Part Number	Description
BC807-25W	45V PNP SMALL SIGNAL TRANSISTOR
BC807-16	45V PNP SMALL SIGNAL TRANSISTOR
BC807-16W	45V PNP SMALL SIGNAL TRANSISTOR
BC807-40	45V PNP SMALL SIGNAL TRANSISTOR
BC807-40W	45V PNP Transistor

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text

Features • Ideally Suited for Automatic Insertion • Epitaxial Planar Die Construction • Complementary NPN Types Available (BC817) • For switching and AF Amplifier Applications • Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2) • Halogen and Antimony Free. "Green" Device (Note 3) • For automotive applications requiring specific change control (i.e. parts qualified to AEC-Q100/101/200, PPAP capable, and manufactured in IATF 16949 certified facilities), please contact us or your local Diodes representative. https://www.diodes.
