GBU410
GBU410 is 4.0A STANDARD RECOVERY BRIDGE RECTIFIER manufactured by Diodes Incorporated.
- Part of the GBU4005 comparator family.
- Part of the GBU4005 comparator family.
GBU4005- GBU410
4.0A STANDARD RECOVERY BRIDGE RECTIFIER
Product Summary
VRRM (V)
50/100/200/400 /600/800/1000
IF (A) 4.0
VF Max (V) @ IF = 2A
IR Max (µA) 5
Features and Benefits
- Glass Passivated Die Construction
- High Case Dielectric Strength of 1500VRMS
- Low Reverse Leakage Current
- Surge Overload Rating to 150A Peak
- Ideal for Printed Circuit Board Applications
- UL Listed Under Recognized ponent Index
File Number E95060
- Lead-Free Finish; RoHS pliant (Notes 1 & 2)
- For automotive applications requiring specific change control (i.e. parts qualified to AEC-Q100/101/104/200, PPAP capable, and manufactured in IATF 16949 certified facilities), please contact us or your...
