SMF4L3.3A - 400W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR

Description

This new generation TVS is designed for transient overvoltage protection.

Power management Automotive applications Battery contacts Mechanical Data Package

Features

  • 400W Peak Pulse Power Dissipation (10µs × 1000µs Waveform).
  • 5V to 200V Standoff Voltages.
  • Provides ESD Protection per IEC61000-4-2 Standard: Air ±30kV, Contact ±30kV.
  • Excellent Clamping Capability.
  • Fast response time: typically less than 1.0ns for Uni-direction, less than 5.0ns for Bi-direction, from 0V to BV min.
  • Lead-Free Finish; RoHS Compliant (Notes 1 & 2).
  • Halogen and Antimony Free. “Green” Device (Note 3).
  • For automo.

📥 Download Datasheet

📁 Similar Datasheet

  • SMF4L30A - TVS Diodes (Littelfuse)
  • SMF4L30A - Surface Mount Transient Voltage Suppressors (ANOVA)
  • SMF4L30A - Surface Mount Transient Voltage Suppressors (SEMIWILL)
  • SMF4L30A - Transient Voltage Suppressor Diode (BOURNS)
  • SMF4L30AT1G - TVS Diodes (Littelfuse)
  • SMF4L30CA - Surface Mount Transient Voltage Suppressors (SEMIWILL)
  • SMF4L33A - TVS Diodes (Littelfuse)
  • SMF4L33A - Surface Mount Transient Voltage Suppressors (ANOVA)
  • SMF4L33A - Surface Mount Transient Voltage Suppressors (SEMIWILL)
  • SMF4L33AT1G - TVS Diodes (Littelfuse)
Other Datasheets by DIODES
  • SMF4L3.3AQ - 400W SURFACE-MOUNT TRANSIENT VOLTAGE SUPPRESSOR
  • SMF4L30A - 400W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR
  • SMF4L30AQ - 400W SURFACE-MOUNT TRANSIENT VOLTAGE SUPPRESSOR
  • SMF4L30AQ - 400W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR
  • SMF4L30CA - 400W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR
  • SMF4L30CAQ - 400W SURFACE-MOUNT TRANSIENT VOLTAGE SUPPRESSOR
  • SMF4L30CAQ - 400W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR
  • SMF4L33A - 400W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR

Full PDF Text Transcription

Click to expand full text
SMF4L3.3A - SMF4L200(C)A Green 400W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR Product Summary (@TA = +25°C) VBR (MIN) 4.1V to 224V IPP (MAX) 1.2A to 43.8A VC (MAX) 8.0V to 328V Features • 400W Peak Pulse Power Dissipation (10µs × 1000µs Waveform) • 5V to 200V Standoff Voltages • Provides ESD Protection per IEC61000-4-2 Standard: Air ±30kV, Contact ±30kV • Excellent Clamping Capability • Fast response time: typically less than 1.0ns for Uni-direction, less than 5.0ns for Bi-direction, from 0V to BV min. • Lead-Free Finish; RoHS Compliant (Notes 1 & 2) • Halogen and Antimony Free. “Green” Device (Note 3) • For automotive applications requiring specific change control (i.e.
