SMF4L36CA - 400W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR

Download the SMF4L36CA datasheet PDF. This datasheet also covers the SMF4L3.3A variant, as both devices belong to the same 400w surface mount transient voltage suppressor family and are provided as variant models within a single manufacturer datasheet.

Description

This new generation TVS is designed for transient overvoltage protection.

Power management Automotive applications Battery contacts Mechanical Data Package

Features

  • 400W Peak Pulse Power Dissipation (10µs × 1000µs Waveform).
  • 5V to 200V Standoff Voltages.
  • Provides ESD Protection per IEC61000-4-2 Standard: Air ±30kV, Contact ±30kV.
  • Excellent Clamping Capability.
  • Fast response time: typically less than 1.0ns for Uni-direction, less than 5.0ns for Bi-direction, from 0V to BV min.
  • Lead-Free Finish; RoHS Compliant (Notes 1 & 2).
  • Halogen and Antimony Free. “Green” Device (Note 3).
  • For automo.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (SMF4L3.3A-DIODES.pdf) that lists specifications for multiple related part numbers.

📁 Similar Datasheet

Part Number Description Manufacturer
SMF4L36CA Surface Mount Transient Voltage Suppressors SEMIWILL
SMF4L36A TVS Diodes Littelfuse
SMF4L36A Surface Mount Transient Voltage Suppressors ANOVA
SMF4L36A Surface Mount Transient Voltage Suppressors SEMIWILL
SMF4L36AT1G TVS Diodes Littelfuse

Other Datasheets by Diodes Incorporated

Part Number Description
SMF4L36CAQ 400W SURFACE-MOUNT TRANSIENT VOLTAGE SUPPRESSOR
SMF4L36CAQ 400W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR
SMF4L36A 400W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR
SMF4L36AQ 400W SURFACE-MOUNT TRANSIENT VOLTAGE SUPPRESSOR
SMF4L36AQ 400W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR

Full PDF Text Transcription

Click to expand full text
SMF4L3.3A - SMF4L200(C)A Green 400W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR Product Summary (@TA = +25°C) VBR (MIN) 4.1V to 224V IPP (MAX) 1.2A to 43.8A VC (MAX) 8.0V to 328V Features • 400W Peak Pulse Power Dissipation (10µs × 1000µs Waveform) • 5V to 200V Standoff Voltages • Provides ESD Protection per IEC61000-4-2 Standard: Air ±30kV, Contact ±30kV • Excellent Clamping Capability • Fast response time: typically less than 1.0ns for Uni-direction, less than 5.0ns for Bi-direction, from 0V to BV min. • Lead-Free Finish; RoHS Compliant (Notes 1 & 2) • Halogen and Antimony Free. “Green” Device (Note 3) • For automotive applications requiring specific change control (i.e.
