SMF4L48CA Overview
Key Specifications
Max Operating Temp: 150 °C
Min Operating Temp: -55 °C
Description
and Applications This new generation TVS is designed for transient overvoltage protection. The combination of small size and high ESD surge capability makes it ideal for use in: - Power management - Automotive applications - Battery contacts Mechanical Data - Package: DO-219AA - Package Material: Molded Plastic, "Green" Molding Compound.
Key Features
- 400W Peak Pulse Power Dissipation (10µs × 1000µs Waveform)
- 5V to 200V Standoff Voltages
- Provides ESD Protection per IEC61000-4-2 Standard: Air ±30kV, Contact ±30kV
- Excellent Clamping Capability
- Fast response time: typically less than 1.0ns for Uni-direction, less than 5.0ns for Bi-direction, from 0V to BV min
- Lead-Free Finish; RoHS Compliant (Notes 1 &
- Halogen and Antimony Free. “Green” Device (Note
- This part is qualified to JEDEC standards (as references in AEC-Q) for High Reliability
