SMF4L8.5CA - 400W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR

Download the SMF4L8.5CA datasheet PDF (SMF4L3.3A included). The manufacturer datasheet provides complete specifications, pinout details, electrical characteristics, and typical applications for 400w surface mount transient voltage suppressor.

Description

This new generation TVS is designed for transient overvoltage protection.

Power management Automotive applications Battery contacts Mechanical Data Package

Features

  • 400W Peak Pulse Power Dissipation (10µs × 1000µs Waveform).
  • 5V to 200V Standoff Voltages.
  • Provides ESD Protection per IEC61000-4-2 Standard: Air ±30kV, Contact ±30kV.
  • Excellent Clamping Capability.
  • Fast response time: typically less than 1.0ns for Uni-direction, less than 5.0ns for Bi-direction, from 0V to BV min.
  • Lead-Free Finish; RoHS Compliant (Notes 1 & 2).
  • Halogen and Antimony Free. “Green” Device (Note 3).
  • For automo.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (SMF4L3.3A-DIODES.pdf) that lists specifications for multiple related part numbers.

📁 Similar Datasheet

  • SMF4L8.5CA - Surface Mount Transient Voltage Suppressors (SEMIWILL)
  • SMF4L8.5A - TVS Diodes (Littelfuse)
  • SMF4L8.5A - Surface Mount Transient Voltage Suppressors (ANOVA)
  • SMF4L8.5A - Surface Mount Transient Voltage Suppressors (SEMIWILL)
  • SMF4L8.5AT1G - TVS Diodes (Littelfuse)
  • SMF4L8.0A - TVS Diodes (Littelfuse)
  • SMF4L8.0A - Surface Mount Transient Voltage Suppressors (ANOVA)
  • SMF4L8.0A - Surface Mount Transient Voltage Suppressors (SEMIWILL)
  • SMF4L8.0AT1G - TVS Diodes (Littelfuse)
  • SMF4L8.0CA - Surface Mount Transient Voltage Suppressors (SEMIWILL)
Other Datasheets by DIODES
  • SMF4L8.5CAQ - 400W SURFACE-MOUNT TRANSIENT VOLTAGE SUPPRESSOR
  • SMF4L8.5CAQ - 400W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR
  • SMF4L8.5A - 400W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR
  • SMF4L8.5AQ - 400W SURFACE-MOUNT TRANSIENT VOLTAGE SUPPRESSOR
  • SMF4L8.5AQ - 400W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR
  • SMF4L8.0A - 400W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR
  • SMF4L8.0AQ - 400W SURFACE-MOUNT TRANSIENT VOLTAGE SUPPRESSOR
  • SMF4L8.0AQ - 400W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR

Full PDF Text Transcription

Click to expand full text
SMF4L3.3A - SMF4L200(C)A Green 400W SURFACE MOUNT TRANSIENT VOLTAGE SUPPRESSOR Product Summary (@TA = +25°C) VBR (MIN) 4.1V to 224V IPP (MAX) 1.2A to 43.8A VC (MAX) 8.0V to 328V Features • 400W Peak Pulse Power Dissipation (10µs × 1000µs Waveform) • 5V to 200V Standoff Voltages • Provides ESD Protection per IEC61000-4-2 Standard: Air ±30kV, Contact ±30kV • Excellent Clamping Capability • Fast response time: typically less than 1.0ns for Uni-direction, less than 5.0ns for Bi-direction, from 0V to BV min. • Lead-Free Finish; RoHS Compliant (Notes 1 & 2) • Halogen and Antimony Free. “Green” Device (Note 3) • For automotive applications requiring specific change control (i.e.
