BAS20W - SURFACE MOUNT FAST SWITCHING DIODE

Diodes Incorporated

Key Features

Fast Switching Speed.
Surface Mount Package Ideally Suited for Automated Insertion.
For General Purpose Switching.

BAS20W surface mount fast switching diode by Diodes Incorporated - Datasheet Preview

Datasheet Details

Part number	BAS20W
Manufacturer	Diodes Incorporated
File Size	365.36 KB
Description	SURFACE MOUNT FAST SWITCHING DIODE
Datasheet	BAS20W Datasheet

📁 Similar Datasheet

Part Number	Description	Manufacturer
BAS20W	Surface Mount Switching Diode	GME
BAS20W	SURFACE MOUNT SWITCHING DIODE	HITANO
BAS20W	Plastic-Encapsulate Diodes	WILLAS
BAS20W	SMD Switching Diode	Formosa MS
BAS20W	Silicon Epitaxial Planar Diodes	BLUECOLOUR

Other Datasheets by Diodes Incorporated

Part Number	Description
BAS21T	SURFACE MOUNT FAST SWITCHING DIODE
BAS21W	SURFACE MOUNT FAST SWITCHING DIODE
BAS116	SURFACE MOUNT LOW LEAKAGE DIODE
BAS116T	SURFACE MOUNT LOW LEAKAGE DIODE
BAS116V	SURFACE MOUNT LOW LEAKAGE DIODE

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text

Features  Fast Switching Speed  Surface Mount Package Ideally Suited for Automated Insertion  For General Purpose Switching Applications  High Conductance  Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)  Halogen and Antimony Free. “Green” Device (Note 3)  Qualified to AEC-Q101 Standards for High Reliability  An Automotive-Compliant Part is Available Under Separate Data Sheet (BAS21WQ) BAS19W - BAS21W SURFACE MOUNT FAST SWITCHING DIODE Mechanical Data  Case: SOT323  Case Material: Molded Plastic, "Green" Molding Compound.
