MMBD4448DW - SURFACE MOUNT SWITCHING DIODE

Key Features

  • Fast Switching Speed.
  • Surface Mount Package Ideally Suited for Automated Insertion.
  • For General Purpose Switching.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
MMBD4448DW Surface Mount Switching Diode Array SeCoS
MMBD4448DW Switching Diodes MCC
MMBD4448DW Surface Mount Fast Switching Diodes LGE
MMBD4448DW SWITCHING DIODE JCET
MMBD4448DW Surface Mount Fast Switching Diodes GME

Other Datasheets by Diodes Incorporated

Part Number Description
MMBD4448 SURFACE MOUNT SWITCHING DIODE
MMBD4448H SURFACE MOUNT SWITCHING DIODE
MMBD4448HTM SURFACE MOUNT FAST SWITCHING DIODE ARRAY
MMBD4448HW SURFACE MOUNT SWITCHING DIODE
MMBD4448V SURFACE MOUNT FAST SWITCHING DIODE

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
Features • Fast Switching Speed • Surface Mount Package Ideally Suited for Automated Insertion • For General Purpose Switching Applications • High Conductance • Miniature Package • Lead Free/RoHS Compliant (Note 1) • Qualified to AEC-Q101 Standards for High Reliability • "Green" Device (Notes 2 and 3) MMBD4448DW SURFACE MOUNT SWITCHING DIODE Mechanical Data • Case: SOT-363 • Case Material: Molded Plastic, “Green” Molding Compound. UL Flammability Classification Rating 94V-0 • Moisture Sensitivity: Level 1 per J-STD-020 • Terminals: Matte Tin Finish annealed over Alloy 42 leadframe (Lead Free Plating). Solderable per MIL-STD-202, Method 208 • Polarity: See Diagram • Weight: 0.
