NA555 - Precision Timer

Product Overview

Diodes

Part number	NA555
Manufacturer	DIODES
File Size	722.29 KB
Description	Precision Timer
Datasheet	NA555 Datasheet
Additional preview pages of the NA555 datasheet.

These devices are precision timing circuits capable of producing accurate time delays or oscillation.

In the timedelay or monostable mode of operation, the timed interval is controlled by a single external resistor and capacitor network.

Timing from microseconds to hours Astable or monostable operation Adjustable duty cycle TTL compatible output can source or sink up to 200mA “Green” Molding Compound (No Br, Sb) Lead Free Finish/ RoHS Compliant (Note 1) 1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied. Please visit our website at http://www. diodes. com/products/lead_free. html. Notes: NE555/SA555/NA555 Document number: DS35112 Rev. 4 - 2 1 of 1.
