PI3WVR13412A
Description
Features
The PI3WVR13412A is a multi-standard video switch with wide voltage range capability. It supports HDMI 2.0 up to 4K2K@60Hz and emerging and proprietary standard. The PI3WVR13412A can pass high-speed signals up to 1.2V peak-to-peak differential with a mon-mode voltage from 0 to 3.4V for TMDS signal. The wide voltage range allows DC-coupled multi-standard operation. Eliminating AC coupling capacitors saves board space and improves signal integrity for dense PCB design. In addition to four high-speed lanes, PI3WVR13412A also switches the DDC and HPD signals using the DDC and HPD channel mux/demux.
Application(s) y mercial Displays y Gaming Monitors y Docking y KVMs y Laptop, AIO PCs
Block Diagram y HDMI 2.0 Electrical Standard patible y 4-lane, 1:2 and 2:1 Switches y Data Rate: 6Gbps for High-Speed Channels y Supports DDC with HPD Channel Mux/Demux at HDMI y -1.2d B Insertion Loss for High-Speed Channels at 3GHz y -3d B Bandwidth for High-Speed Channels: 7GHz y...
