EC10016 Overview
EC10016 is a plete constant-current & constant voltage linear charger for single cell lithium-ion and Lithium-polymer batteries. Its SOT-23 package and low external ponent count make EC10016 ideally suited for portable applications. Furthermore, the EC10016 is specifically designed to work within USB power specification.
EC10016 Key Features
- Programmable Charge Current Up to 800 /1000mA
- No MOSFET, Sense Resistor or Blocking Diode
- Charges Single Cell Li-ion Batteries Directly from USB Port
- Preset 4.22V Charge Voltage with +-1% Accuracy
- 20μA Supply Current in Shutdown
- 2.9V Trickle Charge Threshold
- Soft-Start Limits Inrush Current
- Available in 5-Lead SOT-23 Package
EC10016 Applications
- Programmable Charge Current Up to 800 /1000mA
