EC24C1024A
Description
The EC24C1024A are EEPROM devices that use the industrial standard 2-wire interface for munications. The EC24C1024A contains a memory array of 1024K-bits (131,072x8), which is organized in 25-byte per page. The EEPROM can operate in a wide voltage range from 1.7V to 5.5V which fits most application. This product can provide a low-power 2-wire EEPROM solution. The device is offered in Lead-free, Ro HS, halogen free or Green. The available package types are 8pin SOP, TSSOP. The EC24C1024A is patible with the industrial standard 2-wire bus protocol. If in case the bus is not responded, a new sent Op-code mand will reset the bus and the device will respond correctly. The simple bus consists of the Serial Clock wire (SCL) and the Serial Data wire (SDA). Utilizing such bus protocol, a Master device, such as a microcontroller, can usually control one or more Slave devices, alike this EC24C1024A. The bit stream over the SDA line includes a series of bytes, which identifies a...
