EC3202S Description
EC3202S is a high efficiency step down DC/DC converter operated with current mode and constant frequency. The internal switch and synchronous rectifier are integrated for high efficiency. External Schottky diodes are not required.
EC3202S Key Features
- 2A output current
- Current mode operation
- High efficiency up to 95%
- Shutdown current < 1µA
- 2.5V to 5.5V supply voltage
- Over temperature protection
- Constant frequency operation
- Full duty ratio, 0
- 100% in dropout
- RoHS pliant and Lead (Pb) Free
