ELECTRICAL CHARACTERISTICS
PARAMETERS Frequency Frequency Tolerance Frequency Stability Shunt Capacitance Load Capacitance Drive Level Operating Temperature Storage Temperature Aging (First Year) CONDITIONS @ +25°C -40 ~ +85°C Co Specify in P/N DL Topr Tstg @ +25°C ±3°C CSM-7XDN MIN TYP MAX 3.57 70.000 ± 30 ± 100 7 10 20 Series 500 -40 +85 -55 +125 ±5 UNITS MHz ppm ppm pF pF μW °C °C ppm EQUIVALENT SERIES RESISTANCE/MODE OF OSCILLATION Frequency (MHz) 3.57 ~ 4.999 5.000 ~ 5.999 6.000 ~ 6.999 7.000 ~ 8.999 9.000 ~ 12.999 13.000 ~ 19.999 20.000 ~ 40.000 40.000 ~ 70.000 ESR Ω Max. 150 80 70 60 50 40 30 80 Mode of Osc. Fundamental Fundamental Fundamental Fundamental Fundamental Fundamental Fundamental 3rd Overtone Figure 1) Top, Side, Bottom, and End Crystal is symmetrical, pin 1 & 2 are interchangeable. Figure 2) Suggested land pattern PART NUMBERING GUIDE: Example ECS-200-20-5PXDN-TR ECS - FREQUENCY ABBREVIATION LOAD CAPACITANCE PACKAGE Stability Temperature ECS 200 = 20.000 MHz See P/N...
