SF25 datasheet by EIC Semiconductor.
This datasheet includes multiple variants, all published together in a single manufacturer document.
| Part number | SF25 |
|---|---|
| Datasheet | SF25 SF21 Datasheet (PDF) |
| File Size | 48.84 KB |
| Manufacturer | EIC Semiconductor |
| Description | SUPER FAST RECTIFIER DIODES |
|
|
2.0 Amperes SUPER FAST RECTIFIER DIODES DO-15.
| Brand Logo | Part Number | Description | Other Manufacturers |
|---|---|---|---|
 |
SF25 | SUPER FAST RECTIFIER | Sangdest Microelectronics |
 |
SF25 | Axial Leaded Super Fast Rectifiers | Formosa MS |
 |
SF25 | SUPER FAST RECOVERY SILICON RECTIFIER | KD |
 |
SF25 | 2.0 Amp Super Fast Rectifier 50 to 400 Volts | Micro Commercial Components |
 |
SF25 | 2.0 AMP SUPER FAST RECTIFIERS | Bytes |
View all EIC Semiconductor datasheets
| Part Number | Description |
|---|---|
| SF25G | GLASS PASSIVATED JUNCTION SUPER FAST RECTIFIERS |
| SF21 | SUPER FAST RECTIFIER DIODES |
| SF21G | GLASS PASSIVATED JUNCTION SUPER FAST RECTIFIERS |
| SF22 | SUPER FAST RECTIFIER DIODES |
| SF22G | GLASS PASSIVATED JUNCTION SUPER FAST RECTIFIERS |
| SF23 | SUPER FAST RECTIFIER DIODES |
| SF23G | GLASS PASSIVATED JUNCTION SUPER FAST RECTIFIERS |
| SF24 | SUPER FAST RECTIFIER DIODES |
| SF24G | GLASS PASSIVATED JUNCTION SUPER FAST RECTIFIERS |
| SF26 | SUPER FAST RECTIFIER DIODES |
