BTB04
Features
:
IT(RMS) 4A
VDRM/VRRM 600V and 800 V
VTM 1.55 V
Description
:
TO-220B
TO-220C
2 3 TO-251 T2(2)
1 3
TO-252
T1(1)
G(3)
BTB04 series triacs, with high ability to withstand the shock loading of large current, provide high dv/dt rate with strong resistance to electromagnetic interface. With high mutation performances, 3 quadrants products especially remended for use on inductive load.
Absolute Ratings(limiting values)：
Symbol
Parameter
Tstg
Storage junction temperature range
Tj
Operating junction temperature range
IT(RMS)
RMS on-state current
TO-220BC (TC=95℃) TO-251/TO-252 (TC=86℃)
ITSM
Non repetitive surge peak on-state current (full cycle,F=50Hz)
VDRM
Repetitive peak off-state voltage(Tj =25℃)
VRRM
Repetitive peak reverse voltage(Tj =25℃)
VDSM
Non repetitive surge peak Off-state voltage
VRSM...
