ELM GD25D10B
The GD25D10B (1M-bit) serial flash supports the standard serial peripheral interface (SPI), and supports the Dual Output: Serial Clock, Chip Select, Serial Data I/O0 (SI), O1 (SO). The Dual Output data is transferred with speed of 160Mbits/s. DEVICE OPERATION SPI Mode Standard SPI The GD25D10B features a serial peripheral interface on 4 signals bus: Serial Clock (SCLK), Chip Select (CS#), Serial Data Input (SI) and Serial Data Output (SO).
| Part No. |
GD25D10B |
| Datasheet |
GD25D10B
Download
|
| Manufacturer |
 ELM |
| Description |
Uniform sector dual and quad serial flash |
| Buy |
Stock & Price
|
FEATURES
♦ 1M-bit Serial Flash ♦ Program/Erase Speed - 128K/64K-byte - 256 bytes per programmable page ♦ Standard, Dual Output - Standard SPI: SCLK, CS#, SI, SO, WP# - Dual Output: SCLK, CS#, IO0, O1, WP# ♦ Clock Frequency - 80MHz for fast read with 30PF load - Dual Output Data transfer up to 160Mbits/s ♦ Software/Hardware Write Protection - Write protect all/portion of memory via software - Enable/Disable protection with WP# pin ♦ Cycling endurance - Minimum 100,000 Program/Erase cycles ♦ Data retention - 20-year data retention typical - Page Program time: 0.7ms typical - Sector Erase time: 40ms typical - Block Erase time: 0.2/0.4s typical - Chip Erase time: 0.8/0.4s typical ♦ Flexible Architecture - Sector of 4K-byte - Block of 32/64K-byte ♦ Low Power Consumption - 18mA maximum active current - 5μA maximum power down current ♦ Single Power Supply Voltage - Full voltage range: 2.7~3.6V ♦ Package option - SOP8 150MIL - USON8 3x2mm 28 - 4 Rev.1.0 GD25D10BxIGx Uniform sector dual and quad serial flash 2.
