Datasheet Details
| Part number | ES9039Q2M |
|---|---|
| Manufacturer | ESS Technology |
| File Size | 2.64 MB |
| Description | 32-bit High performance 2-Channel DAC |
| Datasheet | ES9039Q2M-ESS.pdf |
|
|
Overview: Analog Reinvented ES9039Q2M 32-bit High Performance 2 Channel DAC Product Datasheet The ESS SABRE® ES9039Q2M is a high performance 32-bit, 2-channel audio D/A converter. It has been designed for professional applications (mixer consoles, digital audio workstations), audiophiles-grade portable applications (headphones, network streamers and digital music players), and consumer applications (DACs and A/V receivers). The ES9039Q2M uses the newest ESS patented Hyperstream® IV Dual DAC™ technology, and advanced SABRE HiFi® architecture. The ES9039Q2M delivers a performance level that will satisfy the most demanding audiophile and pro-audio enthusiast. The ES9039Q2M SABRE® DAC improves on previous designs to include: • TDM & SPI support for more options in connectivity • Lower power consumption than previous generations which includes the Hyperstream IV DAC modulator • New hardware mode (HW) programmability alleviates I²C/SPI programming for ease of use The versatile audio input port accepts PCM (TDM/LJ/RJ/I²S), DSD, DoP, and S/PDIF formats. The integrates SABRE® DAC supports up to 32-bit 768kHz PCM & DSD1024 audio data via master/slave interface in synchronous and asynchronous sampling modes. The integrated digital regulator reduces PCB area and BOM cost.
| Part number | ES9039Q2M |
|---|---|
| Manufacturer | ESS Technology |
| File Size | 2.64 MB |
| Description | 32-bit High performance 2-Channel DAC |
| Datasheet | ES9039Q2M-ESS.pdf |
|
|
|
32-bit audio DAC with very high dynamic range & ultra-low distortion High performance 32-bit audio DAC with unprecedented dynamic range and ultra-low distortion.
Supports synchronous and asynchronous sampling modes Reduced BOM cost and improved DNR Distortion free signal processing Supports master/slave PCM (TDM, I²S, LJ, RJ), DSD, DoP, S/PDIF formats.
