XPM52C Datasheet 65w Usb Pd Multi-protocol Buck Chip

Manufacturer: FINE MADE ELECTRONICS

Overview: Machine Translated by Google Fuman Microelectronics Group Co., Ltd. FINE MADE MICROELECTRONICS GROUP CO., LTD. XPM52C (Document No.

Datasheet Details

Part number XPM52C
Manufacturer FINE MADE ELECTRONICS
File Size 697.02 KB
Description 65W USB PD Multi-Protocol Buck Chip
Datasheet XPM52C-FINEMADEELECTRONICS.pdf

Key Features

  • ÿ Synchronous switching buck converter - Built-in power MOS - Automatically identify input voltage and adjust output voltage - Input operating voltage up to 31V - Output voltage range: 3.3V to 21V, depending on fast charge ÿ Output fast charge - Support Quick Charge 2.0/3.0/3.0+ protocol - Support Xiaomi CHARGE TURBO 27W protocol - Support Huawei FCP/SCP/HVSCP protocols - Support Samsung AFC protocol - Support VOOC 2.0/4.0 protocol - Support MediaTek PE protocol Automatic adjustment of the pro.

More Datasheets from FINE MADE ELECTRONICS

Part Number Description
XPM5220 65W USB PD and other multi-protocol buck
