Datasheet Summary
SMD Zener Diode
BZT52-S-FL Series
200mW Surface Mount Zener Diodes 2.4V-75V
Formosa MS
Features
- Wide zener voltage range selection, 2.4V to 75V
- 5% tolerance of zener voltage for suffix "C" ex: BZT52C2V4S-FL
- 2% tolerance of zener voltage for suffix "B" ex: BZT52B2V4S-FL
- Flat lead SOD-323FL plastic package
- Surface device type mounting
- RoHS pliant
- Green EMC
- Matte tin(Sn) lead finish
- Lead-free parts meet RoHS requirements
- Suffix "-H" indicates Halogen free parts, ex. ΒΖΤ52C2V4S-FL-H
Mechanical data
- Epoxy:UL94-V0 rated flame retardant
- Case : Molded plastic, SOD-323FL
- Terminals : Solder plated, solderable per
MIL-STD-750, Method 2026
- Polarity : Indicated by...
