BZG05C24
Features
- High reliability
- Voltage range 3.3 V to 100 V
- Fits onto 5 mm SMD footpads
- Ro HS pliant with Halogen-free
Mechanical Data
- Case: SMA molded plastic
- Molding pound, UL flammability classification rating 94V-0
- Terminals: Solder plated, solderable per MIL- STD-202,Method 208
- Polarity: Color band denotes cathode end
Absolute Maximum Ratings (@TA = 25°C unless otherwise specified)
Parameter
Test condition
Power dissipation
Non repetitive peak surge power dissipation Peak reverse power dissipation(non-repetitive) tp=100μs square wave
Rth JA < 30 K/W, Tamb = 60 °C Pdiss 3 W Rth JA < 100 K/W, Tamb = 25 °C tp = 100 μs sq.pulse, Tj = 25 °C prior to surge
Junction temperature
Storage temperature range
Symbol
Value
Unit
P diss
P diss
PZSM
-55 ~ +150
°C
TSTG
-55 ~ +150
°C
Thermal Characteristics
Parameter Junction lead
Junction ambient
Test condition
Symbol
Value
Unit...
