DTA114TL
DTA114TL is Digital Transistor manufactured by Galaxy Microelectronics.
- Part of the DTA114TCA comparator family.
- Part of the DTA114TCA comparator family.
Features
- Epitaxial planar die construction
- Built-in biasing resistors (R1: 10kΩ)
- Also available in lead free version
- Ro HS pliant with Halogen-free
Digital Transistor DTA114T Series
DTA114TCA SOT-23
DTA114TUA SOT-323
DTA114TE SOT-523
Mechanical Data
- Case: SOT-23, SOT-323, SOT-523, SOT-723, DFN1006-3
- Molding pound: UL Flammability Classification Rating
94V-0
- Terminals: Matte tin-plated leads; solderability-per
MIL-STD-202, Method 208
DTA114TM SOT-723
DTA114TL DFN1006-3
Ordering Information
Part Number
DTA114TCA DTA114TUA DTA114TE DTA114TM DTA114TL
Package
SOT-23 SOT-323 SOT-523 SOT-723 DFN1006-3
Shipping Quantity
3000 pcs / Tape & Reel 3000 pcs / Tape & Reel 3000 pcs / Tape & Reel 10000 pcs / Tape & Reel 10000 pcs / Tape & Reel
Marking Code
94 94 94 94 94
Maximum Ratings (@ TA = 25°C unless otherwise specified)
Parameter
Collector-Base Voltage Collector-Emitter Breakdown Voltage Emitter-Base Breakdown Voltage Collector Current (Continuous) Collector Current Power Dissipation Junction Temperature Range Storage Temperature Range
Symbol
SOT-23 SOT-323
VCBO
VCEO
VEBO
IC(Max)
TSTG
Value Unit
SOT-523 SOT-723...
