DTC144ECA - Digital Transistor

Download the DTC144ECA datasheet PDF. This datasheet also covers the DTC114ECA variant, as both devices belong to the same digital transistor family and are provided as variant models within a single manufacturer datasheet.

Key Features

  • Epitaxial planar die construction.
  • Complementary PNP types available(DTA). Pb Lead-free.
  • Built-in biasing resistors,R1=R2.
  • Also available in lead free version.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (DTC114ECA-GME.pdf) that lists specifications for multiple related part numbers.

📁 Similar Datasheet

Part Number Description Manufacturer
DTC144ECA Digital transistors JCET
DTC144ECA DIGITAL TRANSISTOR Rectron Semiconductor
DTC144ECA NPN Digital Transistors MCC
DTC144ECA NPN Digital Transistors SeCoS
DTC144ECA NPN Digital Transistor WILLAS

Other Datasheets by Galaxy Microelectronics

Part Number Description
DTC144EE Digital Transistor
DTC144EUA Digital Transistor
DTC144TCA Digital Transistor
DTC144TE Digital Transistor
DTC144TUA Digital Transistor

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
Production specification Digital Transistor DTC(R1=R2 SERIES)CA FEATURES  Epitaxial planar die construction.  Complementary PNP types available(DTA). Pb Lead-free  Built-in biasing resistors,R1=R2.  Also available in lead free version. APPLICATIONS  The NPN style digital transistor. ORDERING INFORMATION Type No. Marking DTC114ECA DTC124ECA DTC143ECA DTC144ECA 24 25 23 26 SOT-23 Package Code SOT-23 SOT-23 SOT-23 SOT-23 MAXIMUM RATING @ Ta=25℃ unless otherwise specified Symbol Parameter VCC Supply Voltage Input Voltage DTC114ECA VIN DTC124ECA DTC143ECA DTC144ECA Output Current DTC114ECA IO DTC124ECA DTC143ECA DTC144ECA IC(Max.
