GKD07N65
Features
- High breakdown voltage to 650V for improved reliability
- Trench-stop technology offering:
- High speed switching
- High ruggedness, temperature stable behavior
- Short circuit withstand time: 10μs
- Low VCE(SAT)
- Easy parallel switching capability due to positive temperature coefficient in VCE(SAT)
- Enhanced avalanche capability
- Ro HS pliant with Halogen-free
Applications
- Uninterruptible power supplies
- Solar inverter
Mechanical Data
- Case: TO-252
- Molding pound: UL Flammability Classification Rating 94V-0
- Terminals: Matte tin-plated leads; solderability-per MIL-STD-202, Method 208
TO-252
Ordering Information
Part Number GKD07N65
Package TO-252
Shipping Quantity 80 pcs / Tube & 2500 pcs / Tape & Reel
Marking Code KD07N65
Maximum Ratings (@ TC = 25°C unless otherwise specified)
Parameter Collector-to-Emitter Voltage Gate-Emitter Voltage DC Collector Current (TC = 25°C, limited by maximum TJ) DC Collector Current (TC = 100°C, limited by maximum TJ) Diode...
