SOD4006
Features
- For surface mounted applications
- Ideal for automated placement
- Low forward voltage drop
- High forward surge current capability
- Ro HS pliant with Halogen-free
Mechanical Data
- Case: SOD-123FL molded plastic
- Molding pound: UL flammability classification rating 94V-0
- Terminals: Solder plated, solderable per MIL- STD-202, Method 208
- Polarity: Color band denotes cathode end
Maximum Ratings (@ TA = 25°C unless otherwise specified)
Parameter
Peak Repetitive Reverse Voltage RMS Reverse Voltage DC Blocking Voltage Average Forward Output Current Peak Forward Surge Current, 8.3ms Single Half Sine wave
Symbol
VRRM VRMS VDC IF_AV
SOD 4003
200 140 200
IFSM
SOD 4004
400 280 400
SOD 4005 600 420 600 1.0
SOD 4006
800 560 800
SOD 4007
1000 700 1000
Unit
Thermal Characteristics
Parameter
Symbol
SOD 4003
SOD 4004
SOD 4005
SOD 4006
RΘJA
Typical Thermal Resistance
-...
