TFMMT593E
TFMMT593E is PNP Silicon Epitaxial Planar Transistor manufactured by Galaxy Microelectronics.
PNP Silicon Epitaxial Planar Transistor TFMMT593E
Features
- High saturation voltage
- plementary to TFMMT493E
- Excellent h FE linearity
- Halogen free
- Qualified to AEC-Q101 standards for high reliability
Mechanic al Data
- Case: SOT-89
- Molding pound: UL Flammability Classification Rating 94V-0
- Terminals: Matte tin-plated leads; solderability-per MIL-STD-202, Method 208
SOT-89
Ordering Information
Part Number TFMMT593E
Package SOT-89
Shipping Quantity 1000 pcs / Tape & Reel
Marking Code 593
Maximum Ratings (@ TA = 25°C unless otherwise specified)
Parameter Collector-Base Breakdown Voltage Collector-Emitter Breakdown Voltage Emitter-Base Breakdown Voltage Collector Current (continuous)
Symbol VCBO VCEO VEBO IC
Value -120 -100 -5 -1
Unit V V V A
Thermal Characteristics
Parameter Power Dissipation( TA = 25°C) Junction Temperature Range Storage Temperature Range
Symbol Ptot TJ TSTG
Value 550
-55 ~ +150 -55 ~ +150
Unit m W °C °C
STM0617A: March...
